Old 10-16-2012, 03:13 PM   #1
George Juggles
Registered User

George Juggles's Avatar

Join Date: Jan 2012
problem with my amp

SO my amp has been making alot of crackling, and static noises. I figure it is just the tubes, but am not sure. But what I don't understand, is that when I play a B note, no matter where it is, it makes the crackling alot worse. What is causing the problems?

Thanks
George Juggles
__________________
Peavey Classic 30
PRS SE Custom Semi-Hollow
Ibanez TS9
EHX Big Muff USA
BOSS DD3
Joyo Power-Supply 2
George Juggles is offline   Reply With Quote
Old 10-16-2012, 03:16 PM   #2
tubetime86
I don't even play guitar.

tubetime86's Avatar

Join Date: Jul 2008
Microphonic preamp tube is my guess. With the amp on, tap each tube with the rubber end of a pencil and listen. Whichever tube amplifies the 'tap' sound through the speaker is the bad tube... Replace it. Done!
__________________
Quote:
Originally Posted by Cathbard
Quote:
Originally Posted by Raijouta
Unless its electronic drums.

BURN THE WITCH!!!!!
tubetime86 is offline   Reply With Quote
Old 10-16-2012, 03:17 PM   #3
311ZOSOVHJH
G G & A - B A B Y

311ZOSOVHJH's Avatar

Join Date: Mar 2008
Location: Offline
Try swapping some preamp tubes around. Hit the tube pins with some Deoxit contact cleaner and make sure the tubes are all in snug. If a tube lights up real bright turn it off and report back.
__________________
311ZOSOVHJH is offline   Reply With Quote
Old 10-16-2012, 03:21 PM   #4
tubetime86
I don't even play guitar.

tubetime86's Avatar

Join Date: Jul 2008
^I could be wrong, but I believe the fact that it resonates with the 'B' note so distinctly means it is actually a mechanical noise... And the only mechanical noise that I know of that can be amplified through the speaker is microphonic tube noise.

Again I could be wrong... But I don't think I'm wrong in suggesting he rule that out before bothering with anything else.
__________________
Quote:
Originally Posted by Cathbard
Quote:
Originally Posted by Raijouta
Unless its electronic drums.

BURN THE WITCH!!!!!
tubetime86 is offline   Reply With Quote
Old 10-16-2012, 03:38 PM   #5
George Juggles
Registered User

George Juggles's Avatar

Join Date: Jan 2012
I tried tapping them with a pencil, but they didn't amplify the sound at all. I could just here me.
__________________
Peavey Classic 30
PRS SE Custom Semi-Hollow
Ibanez TS9
EHX Big Muff USA
BOSS DD3
Joyo Power-Supply 2
George Juggles is offline   Reply With Quote
Old 10-16-2012, 03:40 PM   #6
311ZOSOVHJH
G G & A - B A B Y

311ZOSOVHJH's Avatar

Join Date: Mar 2008
Location: Offline
Dan, my post does not reflect your post. I just typed up a response and now see that you did too.

I've had microphonic tubes before. As a matter of fact I made a video of it along with the pencil test.

I've also had a crackling preamp tube and that was due to a tube pin arc'ing with the board.

Can't speak to the B note situation.

What amp do you have TS?
__________________

Last edited by 311ZOSOVHJH : 10-16-2012 at 05:06 PM.
311ZOSOVHJH is offline   Reply With Quote
Old 10-16-2012, 03:45 PM   #7
George Juggles
Registered User

George Juggles's Avatar

Join Date: Jan 2012
Peavey classic 30
__________________
Peavey Classic 30
PRS SE Custom Semi-Hollow
Ibanez TS9
EHX Big Muff USA
BOSS DD3
Joyo Power-Supply 2
George Juggles is offline   Reply With Quote
Old 10-16-2012, 04:31 PM   #8
tubetime86
I don't even play guitar.

tubetime86's Avatar

Join Date: Jul 2008
Wow that's odd... Apparently I was wrong, and given that I have no clue.

The fact that it gets worse with a B note means that is the frequency it's resonating at... Which in my mind means mechanical issue... But who knows. I'm gonna wait until a tech, such as Cathbard, joins in.
__________________
Quote:
Originally Posted by Cathbard
Quote:
Originally Posted by Raijouta
Unless its electronic drums.

BURN THE WITCH!!!!!
tubetime86 is offline   Reply With Quote
Old 10-17-2012, 06:58 AM   #9
George Juggles
Registered User

George Juggles's Avatar

Join Date: Jan 2012
Cathbard, get over here
__________________
Peavey Classic 30
PRS SE Custom Semi-Hollow
Ibanez TS9
EHX Big Muff USA
BOSS DD3
Joyo Power-Supply 2
George Juggles is offline   Reply With Quote
Old 10-17-2012, 05:42 PM   #10
George Juggles
Registered User

George Juggles's Avatar

Join Date: Jan 2012
It's been starting to do make the sound worse with a C# note too. It doesn't make the sound when I play an open string
__________________
Peavey Classic 30
PRS SE Custom Semi-Hollow
Ibanez TS9
EHX Big Muff USA
BOSS DD3
Joyo Power-Supply 2
George Juggles is offline   Reply With Quote
Old 10-17-2012, 09:15 PM   #11
Cathbard
Grumpy Old Tech

Cathbard's Avatar

Join Date: Oct 2009
Location: Australia
Highly probable that it's a microphonic tube but it could also just as easily be a poorly seated tube or dirty tube socket. That is affected by resonance too.
__________________
Gilchrist custom guitar
Yamaha SBG500
Telecaster
Randall RM100
Abbey Harmonic II
Marshall JTM45 clone
Marshall JCM900 4102 (modded)
Marshall 18W clone
Fender 5F1 Champ clone
Marshall 1960A
Boss GT-100


Cathbard Amplification
Cathbard is online now   Reply With Quote
Old 10-17-2012, 09:15 PM   #12
311ZOSOVHJH
G G & A - B A B Y

311ZOSOVHJH's Avatar

Join Date: Mar 2008
Location: Offline
Quote:
Originally Posted by George Juggles
I tried tapping them with a pencil, but they didn't amplify the sound at all. I could just here me.

The question is can you hear the tapping through the speaker.

Does that amp have an extension cab out? Try it with an extension cab.

Does your amp have an effects loop? Try plugging guitar into FX return.

Have you swapped any of the tubes around like I suggested?

You could have bought 1 preamp tube and had it in there by now. You could have a microphonic preamp tube like Dan was saying.
__________________
311ZOSOVHJH is offline   Reply With Quote
Old 10-18-2012, 07:23 AM   #13
George Juggles
Registered User

George Juggles's Avatar

Join Date: Jan 2012
It has an extension cab out, but don't have an extension cab.
I will try the fx loop.
I will try swapping around tubes.

And no, I could not hear the tapping through the speaker.
__________________
Peavey Classic 30
PRS SE Custom Semi-Hollow
Ibanez TS9
EHX Big Muff USA
BOSS DD3
Joyo Power-Supply 2
George Juggles is offline   Reply With Quote
Old 10-18-2012, 09:43 AM   #14
311ZOSOVHJH
G G & A - B A B Y

311ZOSOVHJH's Avatar

Join Date: Mar 2008
Location: Offline
Get some of this



and then hit the tube pins with it and work the tube in and out of the socket like it was having sex and then make sure all the tubes are seated down real good like Cath is saying.

Also - is the crackling more of an electronic crackle or more like a loose screw crackle?
__________________
311ZOSOVHJH is offline   Reply With Quote
Old 10-18-2012, 04:03 PM   #15
George Juggles
Registered User

George Juggles's Avatar

Join Date: Jan 2012
I don't really know how to describe it.

I swapped around the tubes, but it still makes the sound. I tried plugging my guitar into the fx return, and it still crackled, but it is not quite as noticible as in the regular input.
__________________
Peavey Classic 30
PRS SE Custom Semi-Hollow
Ibanez TS9
EHX Big Muff USA
BOSS DD3
Joyo Power-Supply 2
George Juggles is offline   Reply With Quote
Old 10-18-2012, 04:09 PM   #16
George Juggles
Registered User

George Juggles's Avatar

Join Date: Jan 2012
Is the deoxit stuff that you have in a tube or spray bottle?
__________________
Peavey Classic 30
PRS SE Custom Semi-Hollow
Ibanez TS9
EHX Big Muff USA
BOSS DD3
Joyo Power-Supply 2
George Juggles is offline   Reply With Quote
Old 10-18-2012, 04:51 PM   #17
311ZOSOVHJH
G G & A - B A B Y

311ZOSOVHJH's Avatar

Join Date: Mar 2008
Location: Offline
spray bottle

it is contact cleaner

I'm starting to think that won't fix anything but in general - it is good to keep your pins and sockets clean

I've heard of 'ghost notes' before but I wouldn't know if that has anything to do with it or not without doing more research.

Separately-

Sometimes in combo's when the tubes are real close to the speaker like that you can get some weird stuff. A microphonic tube would not necessarily show itself on a pencil test. But with the speaker real close like that then it could highten a note I suppose. That was partly why I asked about an extension cab. Can you take your amp to a store and plug it into a cab and see what happens.

I personally would swap some tubes around for now.
__________________

Last edited by 311ZOSOVHJH : 10-18-2012 at 05:14 PM.
311ZOSOVHJH is offline   Reply With Quote
Old 10-18-2012, 04:53 PM   #18
Offworld92
One among the fence.

Offworld92's Avatar

Join Date: Nov 2009
Location: Southern California, USA
Quote:
Originally Posted by 311ZOSOVHJH

and then hit the tube pins with it and work the tube in and out of the socket like it was having sex



That was really funny to me for some reason.

Carry on.
__________________
Spin 'round carousel when your horse isn't screwed in.

Epiphone Firebird VII
Ibanez S420
LTD H-301
Peavey Predator USA
Ibanez RG520
Line 6 Pod HD500X
VHT Special 6 Ultra
Pedulz
Offworld92 is offline   Reply With Quote
Old 10-18-2012, 05:26 PM   #19
311ZOSOVHJH
G G & A - B A B Y

311ZOSOVHJH's Avatar

Join Date: Mar 2008
Location: Offline
Here is my pencil test vid.




Also - does your amp have tube retainers on the power tubes?
__________________
311ZOSOVHJH is offline   Reply With Quote
Old 10-18-2012, 05:49 PM   #20
George Juggles
Registered User

George Juggles's Avatar

Join Date: Jan 2012
What do you mean by a retainer? The little metal things that go down and around the tip of the tube?
__________________
Peavey Classic 30
PRS SE Custom Semi-Hollow
Ibanez TS9
EHX Big Muff USA
BOSS DD3
Joyo Power-Supply 2
George Juggles is offline   Reply With Quote
