Old 01-08-2013, 01:26 AM   #1
gregs1020
Hi mom!

gregs1020's Avatar

Join Date: Dec 2007
The Ultimate Les Paul Thread - V1

I don't think it's possible to really list every company that has made a version of the Les Paul.

Okay - maybe it's possible, but i'm not going to try to do it.

Gibson alone has made so many different versions of the guitar it's almost impossible to list every single model they've produced since 1952, let alone all of the versions made since by other companies.

So let's break it down into historical years and some basic changes.

I'll use Les Paul Standards for example, but Juniors and Customs were made over many of these years as well.

YEAR ONE - THE 1952 LP


1953 - bridge changed from '52.


1956 - bridge changed to the tune o matic


1957 brings us the humbuckers. This one was Duanne Allmans


1958 brings us the burst.


the 1959 brings a thinner neck than the previous models and slightly taller frets


the 1960 brings still a thinner neck.



and that was the end of the single cut maple top until 1968.

the 1961 Les Paul



between '61 and '68, during the hard rock "explosion" if anyone wanted the "old style" les paul with buckers they had to get a '57 - '60 which in part made them so desirable and growing demand eventually helped persuade gibson bring them back in '68.

so in a way, any les paul made after '60 was a "reissue".


But anyway in this thread we can, as a community, answer questions about different models, changes, pros, cons, values, favorites, etc.

This is not a "my guitar is better than your guitar" thread, what may be overpriced to you may not be to someone else. So let's just say some guitars may or may not be a better "value" and leave it at that.

This thread is not exclusive to Gibsons. Plenty of guitar manufacturers make Les Paul type guitars. Gibson, IMO, does a fine job of it. So do plenty of others, Tokai, Navigator, Burny, Orville, Epiphone, Agile, ESP/LTD, Edwards, on and on and on...

We can basically try to stay within the scope of single cut guitars (although Yamaha does a fine job at having two cutaways) with two humbuckers is close enough.

Questions about anything pertaining to the LP guitar is welcome, flaming or any other asinine behavior will be met with a backhand by a wet glove.

Let's help each other discover, learn, appreciate, and find good LP type guitars.

Maybe even spam a little.

At last count I've had 9 gibson LPs ranging from studios to custom shop built models, and 7 non-gibson LPs. (still have a couple of the non-gibsons, some of my gibsons are floating around this site and others).

we can get into the urgent matter of pickguard on or off, and the benefits of topwrapping at some point.
__________________
Quote:
Originally Posted by Cathbard
I may just make you an honorary Aussie for that one greg.

if i've ever aspired for anything...

Last edited by gregs1020 : 01-09-2013 at 12:40 AM.
gregs1020 is offline   Reply With Quote
Old 01-08-2013, 01:31 AM   #2
gregs1020
Hi mom!

gregs1020's Avatar

Join Date: Dec 2007
While this post will be primarily about modern made Gibson Les Pauls..

There are two locations/plants making "Gibson Les Paul" guitars. They are Gibson USA and Gibson Custom Shop.

*Partially borrowed from a sticky over at MLP but modified to add in some additional information.
Gibson USA
Weight-relief started around 1982/1983. Every Gibson USA Les Paul between 1982 - 2007 is weight-relieved. They do not have solid-body construction. Weight-relief is also known as "swiss cheese holes" and refers to the nine holes drilled out of the body in order to reduce the weight of the guitar.

Chambering officially began for 2007 but the late 2006s are also chambered. Any Les Paul made after October 2006 maybe or likely is chambered. Every 2007 and newer Gibson USA Les Paul is chambered, except for the Les Paul Traditional. The Les Paul Traditional has swiss cheese holes up until the 2013 models which are now solid construction. Chambering is essentially hollowing out the body. Again, this is in order to reduce the weight of the guitar.

Gibson Custom Shop
Gibson's Custom Shop makes regular production guitars and historic reissues. The regular production guitars, such as the Les Paul Custom, are also weight-relieved. They do not have solid-bodies.

The historic reissues are solid. All historic reissues, be it Standards or Customs, are solid. The exception being the chambered reissues. Chambered reissues are often referred to as Cloud 9 guitars. They are identified by their serial number, which begins with CR. chambered-reissue.org

So,

A 2003 Les Paul Classic is weight-relieved
A 2008 '57 reissue is solid
A 1995 Les Paul Standard is weight-relieved
A 2009 Chambered '58 reissue is chambered
A 2008 Les Paul Studio is chambered
A 1987 Les Paul Custom is weight-relieved
etc.

If you put on your x-ray goggles, this is what a chambered Les Paul would look like:


This is what a weight-relieved Les Paul would look like:


The 2012 chambering looks like this.



Neck tenons


Some Les Pauls have long neck tenon, while others do not.

Short: Standards (before the 2008 "new" Standard), Customs, Studios Classics.
Long: Historic reissues, 2008 Standards.

Norlin
Gibson guitars made between 1968 - 1986.
Some common features of the Norlin era guitar are the larger headstocks, pancake type body construction and neck volute.

Norlin era headstocks are a bit wider like this one.


neck volutes, both large and small.


Pancake body example.


Historic Reissues
R2 = reissue of the 1952 Gibson Les Paul
R9 = reissue of the 1959 Gibson Les Paul
CR8 = chambered reissue of the '58 Gibson Les Paul
There is no R3 or R5.

Historic Customs are often referred to as B4, B7, R4BB or R7BB. BB meaning Black Beauty.

Gibson's VOS - Vintage Original Spec line. The terms VOS, historic, reissue & historic reissue all refer to the same guitar. There is only one difference, VOS refers to the aged finish on the top and hardware. The ones that do not have the VOS finish are referred to as "gloss" or "high gloss" reissues because (obviously) they have a high gloss finish. Websites like Guitar Center list the two guitars as VOS and "reissue." Reissue refers to the high gloss. I think this has caused some confusion with some people but rest assured, they are all the same guitar. Again, one looks brand new and the other does not look brand new - that's the only difference. VOS costs $300 less.

Historic Customs
Standards have mahogany bodies and maple tops. Historic Customs have mahogany bodies and mahogany tops (while modern/regular Customs have maple tops). The Custom will likely weight around a pound heavier but that's about it for differences.

1968 Reissue
Another reissue that never seems to be on gibson.com is the '68RI. These are the same as the B7s, only difference is they have maple tops, different pickups and Gibson USA electronics.

R8 vs. R9
This question gets asked a lot !!
They are the same guitar. All reissues are essentially the same guitar with minor differences. These differences are neck thicknesses, weight of each individual guitar & tops. R8 guitars are typically plain tops and R9s are typically flamed tops, but flamed top R8s do exist. The best way to get an understanding of the neck sizes is to actually play them. Me explaining that R8s have thicker necks than R9s and R7s have thicker necks than R8s doesn't mean jack unless you sit down with the guitar and see for yourself.

R9s list for $1,500 - $2,000 more than R8s. Why? The answer is because R9s have flame maple tops and the R9 should weigh less than the R8. That's it.
Here's a great pic taken from inside Gibson's Custom Shop
__________________
Quote:
Originally Posted by Cathbard
I may just make you an honorary Aussie for that one greg.

if i've ever aspired for anything...

Last edited by gregs1020 : 01-10-2013 at 02:05 PM.
gregs1020 is offline   Reply With Quote
Old 01-08-2013, 01:32 AM   #3
Roc8995
Moderator

Roc8995's Avatar

Join Date: Nov 2005
Location: Madison, Wisconsin
Fix'd thread title

Might as well start it off properly.


__________________
rr, pe&a
Roc8995 is offline   Reply With Quote
Old 01-08-2013, 01:39 AM   #4
gregs1020
Hi mom!

gregs1020's Avatar

Join Date: Dec 2007
oh we do love ebony les pauls.

fun fact - gibson never made a black guitar - only "ebony".

my burny FLG70 during the refin.



the finished product.

__________________
Quote:
Originally Posted by Cathbard
I may just make you an honorary Aussie for that one greg.

if i've ever aspired for anything...
gregs1020 is offline   Reply With Quote
Old 01-08-2013, 02:19 AM   #5
Wisthekiller
UG's Nigel Tufnel

Wisthekiller's Avatar

Join Date: Dec 2009
The Agile will look MUCH better when it's done.



Gibson Les Paul Special Faded.


__________________
Check my Firebird build!-Comment on that bitch so I don't have to double post, even if it's a friendly "YOU SUCK!"

Upright fretted electric bass build!
Wisthekiller is offline   Reply With Quote
Old 01-08-2013, 02:42 AM   #6
RiseTheFallen
Registered User

RiseTheFallen's Avatar

Join Date: Apr 2011
Location: Sweden


ESP Eclipse II, if that counts...
RiseTheFallen is offline   Reply With Quote
Old 01-08-2013, 03:27 AM   #7
dannyalcatraz
Registered User

dannyalcatraz's Avatar

Join Date: Dec 2008
OK...I have a question regarding an LP style guitar:

I have a Dean Special Select EVO- arched maple top (quilted tiger's eye finish) with a mahogany body- from about 2003. Everything about this guitar is good except the pickups, which, compared to my better guitars, are muddy. So I'm upgrading them in 2013.

I'm planning on a Bareknuckle Steve Stevens Rebel Yell in the bridge and their Mississippi Queen HB-sized P90 in the neck- fell in love with them listening to samples.

The question: will those pickups work well with that body & top wood combo?

(For the record: amp is a 40w Fender HRD Combo.)
__________________
Sturgeon's 2nd Law, a.k.a. Sturgeon's Revelation: “Ninety percent of everything is crap.”

Why, yes, I am a lawyer- thanks for asking!

Last edited by dannyalcatraz : 01-08-2013 at 03:29 AM.
dannyalcatraz is online now   Reply With Quote
Old 01-08-2013, 03:35 AM   #8
HenryB
Registered User

HenryB's Avatar

Join Date: Nov 2009
Location: Essex, UK
UK

Les Paul Standard Faded (and my Les Paul Junior, too):


Close up of the Standard:
__________________
My Current Gear
Gibson Les Paul Standard Faded (Cherry Burst) || Gibson Les Paul Junior (Vintage Sunburst)
Marshall 1987X and 1960AX || Weber Mass 100
Fulltone OCD pedal || Ibanez TS-9 tube screamer || Big Muff Pi with Tone Wicker || Boss AC2
HenryB is offline   Reply With Quote
Old 01-08-2013, 08:05 AM   #9
Tom 1.0
Hot For Teacher

Tom 1.0's Avatar

Join Date: Jun 2007
Location: UK


Got to have a Gold Top on page one.
__________________
Quote:
Originally Posted by Lemoninfluence
I'm not familiar with police procedures.



1977 Burny FLG70
Tom 1.0 is offline   Reply With Quote
Old 01-08-2013, 09:47 AM   #10
gregs1020
Hi mom!

gregs1020's Avatar

Join Date: Dec 2007
^ hell yeah.
Quote:
Originally Posted by dannyalcatraz
I'm planning on a Bareknuckle Steve Stevens Rebel Yell in the bridge and their Mississippi Queen HB-sized P90 in the neck- fell in love with them listening to samples.

The question: will those pickups work well with that body & top wood combo?

(For the record: amp is a 40w Fender HRD Combo.)

the rebel yell works for steve stevens in his gibsons so i can't see why it wouldn't.

and a p-90 in the neck of a LP is a always a good match.

__________________
Quote:
Originally Posted by Cathbard
I may just make you an honorary Aussie for that one greg.

if i've ever aspired for anything...
gregs1020 is offline   Reply With Quote
Old 01-08-2013, 10:18 AM   #11
Tom 1.0
Hot For Teacher

Tom 1.0's Avatar

Join Date: Jun 2007
Location: UK
Didn't work too great in mine.
__________________
Quote:
Originally Posted by Lemoninfluence
I'm not familiar with police procedures.



1977 Burny FLG70
Tom 1.0 is offline   Reply With Quote
Old 01-08-2013, 02:58 PM   #12
JKHC
Registered User

JKHC's Avatar

Join Date: Apr 2011
Slash fanboys....
__________________
Quote:
Originally Posted by FEngHLyan
She will join the prom.

She insists to wear this lights.

I don't think so.

How can I persuade her?
JKHC is offline   Reply With Quote
Old 01-08-2013, 03:29 PM   #13
randomguy2000
<3's ToppScore

randomguy2000's Avatar

Join Date: Apr 2012
Quote:
Originally Posted by JKHC
Slash fanboys....

this
(and sexy standard Henry)
__________________
Quote:
Originally Posted by kangaxxter
Tone is in the fingers.

What you really need is a new amp.

(Anything I missed?)



Quote:
Originally Posted by Robbgnarly
I have been hearing about MG amps lately. I have heard good about them, but only a few times have they been talked about here.

randomguy2000 is offline   Reply With Quote
Old 01-08-2013, 03:31 PM   #14
LP1951
Registered User

Join Date: Dec 2012
Location: Nashville
Quote:
Originally Posted by JKHC
Slash fan...


And Page & Bloomfield & Clapton & Richards & Rhodes & almost every other guitar player who has played LPs in the past 60 years.
__________________
“You’re always learning about this thing every time you pick it up.” Keith Richards
LP1951 is offline   Reply With Quote
Old 01-08-2013, 03:47 PM   #15
Mephaphil
No empty frets.

Mephaphil's Avatar

Join Date: Apr 2012
Slash is awesome. I see no problem in being a fan of his.
__________________
Quote:
Originally Posted by Shredwizard445
Go ahead and spend your money, I don't care. It won't make you sound better.


Quote:
Originally Posted by Shredwizard445
Sure upgrading your gear will make you sound better.


Mephaphil is offline   Reply With Quote
Old 01-08-2013, 04:11 PM   #16
dannyalcatraz
Registered User

dannyalcatraz's Avatar

Join Date: Dec 2008
Without naming names, I'll just say that a LOT of great R&R of the past was played on LPs, and the future doesn't look all that different.
__________________
Sturgeon's 2nd Law, a.k.a. Sturgeon's Revelation: “Ninety percent of everything is crap.”

Why, yes, I am a lawyer- thanks for asking!
dannyalcatraz is online now   Reply With Quote
Old 01-08-2013, 04:14 PM   #17
gregs1020
Hi mom!

gregs1020's Avatar

Join Date: Dec 2007
i'm probably more of a page fanboi, but i'm not a fan of cherry burst LPs.

just a preference thing, to each their own.

Quote:
Originally Posted by Tom 1.0
Didn't work too great in mine.

care to elaborate oh mister of so few words?
__________________
Quote:
Originally Posted by Cathbard
I may just make you an honorary Aussie for that one greg.

if i've ever aspired for anything...
gregs1020 is offline   Reply With Quote
Old 01-08-2013, 04:29 PM   #18
dannyalcatraz
Registered User

dannyalcatraz's Avatar

Join Date: Dec 2008
Yeah!

Between Tom & Greg, I've gotten answers, but no wiser!
__________________
Sturgeon's 2nd Law, a.k.a. Sturgeon's Revelation: “Ninety percent of everything is crap.”

Why, yes, I am a lawyer- thanks for asking!
dannyalcatraz is online now   Reply With Quote
Old 01-08-2013, 04:46 PM   #19
WholeLottaIzzy
UGs Only Rhythm Guitarist

WholeLottaIzzy's Avatar

Join Date: Apr 2011
Location: In a cave
My favourite thing in the whole world... My Gibson Les Paul Standard Faded in Honeyburst. Had someone offer me an R8 in exchange for my faded but I refused. I am never getting rid of that LP. I couldn't. It was also made on my bday too, which is a nice bonus.



And I have another very special Les Paul on the way. Gunna have to wait a while for that one though...

Sweet, didn't even notice the other faded up there! Don't see them too often on this site.
__________________
The blues ain't nothin' but a good man feelin' bad.

Last edited by WholeLottaIzzy : 01-09-2013 at 07:55 AM.
WholeLottaIzzy is offline   Reply With Quote
Old 01-08-2013, 05:25 PM   #20
Mephaphil
No empty frets.

Mephaphil's Avatar

Join Date: Apr 2012
It's messy cos I am a man! Arrrr!



Complete with left hand truss rod cover!!!

Nice guitars guys!
__________________
Quote:
Originally Posted by Shredwizard445
Go ahead and spend your money, I don't care. It won't make you sound better.


Quote:
Originally Posted by Shredwizard445
Sure upgrading your gear will make you sound better.



Last edited by Mephaphil : 01-08-2013 at 05:34 PM.
Mephaphil is offline   Reply With Quote
Reply


Thread Tools Rate This Thread
Rate This Thread:

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

vB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Forum Jump



All times are GMT -4. The time now is 10:41 PM.

Forum Archives / About / Terms of Use / Advertise / Contact / Ultimate-Guitar.Com © 2014
Powered by: vBulletin Version 3.0.9
Copyright ©2000 - 2014, Jelsoft Enterprises Ltd.
