05-25-2006, 08:39 PM
|
#41 | ||
|
the Jargonaut
Join Date: Apr 2005
|
Quote:
great, person x could likely work out the volume/ wah switch if he/she knew how some of the other stuff worked
__________________
Fender blues deluxe and an Epiphone Les paul Quote:
|
||
|
|
|
05-25-2006, 08:59 PM
|
#42 |
|
My Avatar Kills Fascists!
Join Date: May 2005
Location: Portland, OR
|
^Posted, look at the bottom of the last page.
__________________
I'm not very active here on UG currently. I'm a retired Supermod off to the greener pastures of the real world.
|
|
|
|
|
05-26-2006, 11:15 AM
|
#43 |
|
...
Join Date: Jan 2005
Location: On earth
|
****!!!!!!!!
My pedal wont work! first of all, I tried it and it was fine, but after about a minute it seemed like it was stuck in one wah postition. It kept suddenly cutting out and in, stciking in various positions. I then turned it off and came back 5 mins later. Now when I turn it on,it literally acts like a killswitch.I just cant hear anything in clean and it take away 99% of my gain when on distortion. WHY!!!!???? Whats theproblem? The Inductor looks wierd, it isnt just a black round circle. Its a 15 year old GCB-95. Help please! |
|
|
|
|
05-26-2006, 11:31 AM
|
#44 |
|
My Avatar Kills Fascists!
Join Date: May 2005
Location: Portland, OR
|
^If you modded it, check all the solder joints. And also remember, if you took out the buffer, you need to add the new switch too.
__________________
I'm not very active here on UG currently. I'm a retired Supermod off to the greener pastures of the real world.
|
|
|
|
|
05-27-2006, 07:31 AM
|
#45 |
|
...
Join Date: Jan 2005
Location: On earth
|
Problem Solved!
When I was rocking the treadle, the thing that was ment to be turning wasnt.Its fine now! BUT NEW PROBLEM! It has like, 0 sweep! How can I mod it to get loads of sweep, rather than it suddenly changing? |
|
|
|
|
05-29-2006, 02:21 PM
|
#46 |
|
My Avatar Kills Fascists!
Join Date: May 2005
Location: Portland, OR
|
^Mess with the 1.5k resistor. That will help to a certain extent, after that I think a new pot might be in order.
__________________
I'm not very active here on UG currently. I'm a retired Supermod off to the greener pastures of the real world.
|
|
|
|
|
06-04-2006, 05:32 AM
|
#47 | |
|
UG's Swede
Join Date: Oct 2005
Location: Sweden
|
Åinkyim doing this mod, but the pic doesnt show!
__________________
Quote:
18watter video demo My band Recognised by the Official EG/GG&A Who To Listen To List 2009 |
|
|
|
|
|
06-04-2006, 07:38 AM
|
#48 |
|
My Avatar Kills Fascists!
Join Date: May 2005
Location: Portland, OR
|
__________________
I'm not very active here on UG currently. I'm a retired Supermod off to the greener pastures of the real world.
|
|
|
|
|
06-04-2006, 05:06 PM
|
#49 | |
|
UG's Swede
Join Date: Oct 2005
Location: Sweden
|
^Thanks. Ill drop by ELFA (swedish electronic store) and get all the componenets.
Could you make a list of all hte components i need?
__________________
Quote:
18watter video demo My band Recognised by the Official EG/GG&A Who To Listen To List 2009 Last edited by Gabel : 06-04-2006 at 06:19 PM. |
|
|
|
|
|
06-06-2006, 02:50 AM
|
#50 |
|
My Avatar Kills Fascists!
Join Date: May 2005
Location: Portland, OR
|
^It says right on the picture man...just look at all the stuff on there! Heh, you could even print out the picture and just show it to them.
NOW, for all you Zakk fans, heres the only difference between the Original Crybaby, and the Zakk signature: c1-.01uF c8-.22uF Fasel inductor metal film resistors film caps PCB shot: http://i59.photobucket.com/albums/g...09/DSC00560.jpg Look, it even uses the GCB-95 circuit board  Hope this is still interesting to you guys...
__________________
I'm not very active here on UG currently. I'm a retired Supermod off to the greener pastures of the real world.
|
|
|
|
|
06-09-2006, 12:13 PM
|
#51 |
|
...
Join Date: Jan 2005
Location: On earth
|
Do u know any sites that refer specifically 2 the Rev E board? (1990)
|
|
|
|
|
06-09-2006, 07:27 PM
|
#52 |
|
My Avatar Kills Fascists!
Join Date: May 2005
Location: Portland, OR
|
^I know of one, but I've gotta find the link again.
You don't need the pic though, just read the resistor and cap codes and make the appropriate changes..
__________________
I'm not very active here on UG currently. I'm a retired Supermod off to the greener pastures of the real world.
|
|
|
|
|
07-03-2006, 06:52 PM
|
#53 |
|
UG's Wah *****
Join Date: Feb 2005
Location: Texas
|
I just took out my chip to my Vox wah, super easy. I was wondering how much a whole new better chip would cost?
__________________
Amp: Fender Blues Jr (GH1230 Celestion Speaker) Pedals Barber DD Wilson WH-10 Clone Ibanez WH10 V2 Pitchblack Tuner Boss DD-3 Guitars: 06' Custom Fender Strat Lindy Fralin Blues Specials, Callaham Tremolo 09' Olympic White Stratocaster |
|
|
|
|
07-03-2006, 06:55 PM
|
#54 |
|
UG's Wah *****
Join Date: Feb 2005
Location: Texas
|
Whats the big black thing on the board? And how do you desolder things?
__________________
Amp: Fender Blues Jr (GH1230 Celestion Speaker) Pedals Barber DD Wilson WH-10 Clone Ibanez WH10 V2 Pitchblack Tuner Boss DD-3 Guitars: 06' Custom Fender Strat Lindy Fralin Blues Specials, Callaham Tremolo 09' Olympic White Stratocaster |
|
|
|
|
07-03-2006, 07:02 PM
|
#55 |
|
My Avatar Kills Fascists!
Join Date: May 2005
Location: Portland, OR
|
It's an inductor. To desolder, use a desoldering braid or sucker.
__________________
I'm not very active here on UG currently. I'm a retired Supermod off to the greener pastures of the real world.
|
|
|
|
|
07-03-2006, 07:08 PM
|
#56 |
|
UG's Wah *****
Join Date: Feb 2005
Location: Texas
|
What would be a good really vocal inductor?
__________________
Amp: Fender Blues Jr (GH1230 Celestion Speaker) Pedals Barber DD Wilson WH-10 Clone Ibanez WH10 V2 Pitchblack Tuner Boss DD-3 Guitars: 06' Custom Fender Strat Lindy Fralin Blues Specials, Callaham Tremolo 09' Olympic White Stratocaster |
|
|
|
|
07-03-2006, 07:11 PM
|
#57 |
|
My Avatar Kills Fascists!
Join Date: May 2005
Location: Portland, OR
|
Fasel?
Halo?
__________________
I'm not very active here on UG currently. I'm a retired Supermod off to the greener pastures of the real world.
|
|
|
|
|
07-03-2006, 07:33 PM
|
#58 |
|
UG's Wah *****
Join Date: Feb 2005
Location: Texas
|
Is it 68k or 6.8k?
__________________
Amp: Fender Blues Jr (GH1230 Celestion Speaker) Pedals Barber DD Wilson WH-10 Clone Ibanez WH10 V2 Pitchblack Tuner Boss DD-3 Guitars: 06' Custom Fender Strat Lindy Fralin Blues Specials, Callaham Tremolo 09' Olympic White Stratocaster Last edited by The Master Plan : 07-03-2006 at 07:39 PM. |
|
|
|
|
07-03-2006, 07:35 PM
|
#59 |
|
UG's Wah *****
Join Date: Feb 2005
Location: Texas
|
I was looking at the Halo one on Ebay. Would I just de solder the old one and pin it down then solder it? Would that be it?
__________________
Amp: Fender Blues Jr (GH1230 Celestion Speaker) Pedals Barber DD Wilson WH-10 Clone Ibanez WH10 V2 Pitchblack Tuner Boss DD-3 Guitars: 06' Custom Fender Strat Lindy Fralin Blues Specials, Callaham Tremolo 09' Olympic White Stratocaster |
|
|
|
|
07-08-2006, 12:35 AM
|
#60 | |
|
Gear-Monkey
Join Date: Jul 2006
Location: Big Rapids, Michigan
|
Quote:
Can you be more descriptive for simple minds like me? I just did the range adjustment but the original wah is still to "intense" (lack of a better word) I think I can do the Zakk mod if I knew where to get the parts... Does radio shack have them? (I'm also going to do a LED mod) |
|
|
|
|
 |
«
