FINISHED PICS PAGE 9

Simple build, yet my first one.

Specs:
Mahogany Body
Bolt on Guatambu Neck with Ebony Fretboard.
Dual Humbucker
Akkord hardware
Lace Pickups

Kisekae Mock Up:



Getting the body wood tomorrow.

My advantages: Wood is cheaper here than in the states. 100GBP is quite a lot of money at least here.

Cheers.
Last edited by divinorum69 at Apr 26, 2010,
deftonesordie
ENGL Fireball 100 Abuser
Join date: Oct 2007
513 IQ
#2
this thing should rock the living hell out of some 100GBP builds (namely mine... :sad

Pics!
------

Shwiggity.
divinorum69
Construction Manager
Join date: May 2007
1,803 IQ
#3
Quote by deftonesordie
this thing should rock the living hell out of some 100GBP builds (namely mine... :sad

Pics!


Tommorrow Ill post wood blank pics!

im quite excited, its gonna be my first build. Ive been practicing routing all day long on scraps, im dirty and quite tired but im improving
deftonesordie
ENGL Fireball 100 Abuser
Join date: Oct 2007
513 IQ
#4
Good! Practice makes perfect!

as well: Templates make EVERYTHING easier. If you can, make a plywood / MDF template before you start, it'll make the routing process much easier.
------

Shwiggity.
chuckflan333
Mmm, yeah
Join date: Sep 2005
778 IQ
#5
I be excited. I'm looking forward to this, and starting mine.
Gear
Fender Thinline Telecaster Deluxe

1983 Aria Pro II XX Deluxe Flying V

2007 S101 EGU34

1963 Kay Vanguard

1964 Kay Vanguard

AXL Badwater SRO

Hondo Strat

1974 Acoustic(brand) 134 4x10 combo

Epiphone Valve Jr.
bv310
GB&C's Very Own Brock!!!
Join date: Oct 2007
1,721 IQ
#7
i'm voting for the non-bridge plate one. Your build is gonna rock mine
R.I.P. Les Paul, 1915-2009

A man chooses, a slave obeys.
Warp3r
Panned
Join date: Oct 2008
436 IQ
#8
Quote by divinorum69
I like everyones enthusiasm.

I made a template, have to smooth it a bit yet, with some sanding paper. I took the **** wood out of an old school desk.





will do the bridge humbucker once I decided which bridge to use.
Options:



or




OMG that loos like an ipod somehow or am i the only one seeing that (it would be a pretty kickin ipod at that ) good luck dude
Quote by will123456789

and mate: ure the first 08er to make me laugh kudos

Quote by Mr. La Fritz
Turn it off and on again.


^ Golden computer rule.

Quote by Spamwise
I've had a hooker die once. I love getting free stuff.
chuckflan333
Mmm, yeah
Join date: Sep 2005
778 IQ
#9
That was random.

I vote traditional tele bridge. Looks so much better to me.
Gear
Fender Thinline Telecaster Deluxe

1983 Aria Pro II XX Deluxe Flying V

2007 S101 EGU34

1963 Kay Vanguard

1964 Kay Vanguard

AXL Badwater SRO

Hondo Strat

1974 Acoustic(brand) 134 4x10 combo

Epiphone Valve Jr.
vinc3nt
Fear is your only god
Join date: Jul 2008
232 IQ
#11
nice!
Quote by maiden03
Ahhh damn you vinc3nt!

Downpressor man

Where you gonna run to

All along that day


੧_\\\
oneblackened
Better Than You At Mixing
Join date: Oct 2007
3,210 IQ
#12
Nice! Now that you mention it, the Tele HB bridge does look like a new iPod nano.
Current Gear:
LTD MH-400
PRS SE Custom 24 (BKP C-Bomb/VHII)
ESP Horizon NT-7 (SD Full Shreds)
UA Apollo Twin Duo
Peavey Revalver 4, UAD Friedman BE100/DS40
Focal Alpha 65 monitors
Quote by Anonden
You CAN play anything with anything....but some guitars sound right for some things, and not for others. Single coils sound retarded for metal, though those who are apeshit about harpsichord probably beg to differ.
420 FREAK
Registered User
Join date: Jan 2007
3,342 IQ
#13
When making templates for any straight parts it is best to use doublestick tape to stick a piece of wood where the line is and use a top mounted bearing bit (the same you would use for routing the cavities in the guitar) that way it's perfect. The neck pockets where you want it the best. If it's covered up by a pickguard , cover or anything it really doesn't have to be perfect at all but if your like me it will bother you.
deftonesordie
ENGL Fireball 100 Abuser
Join date: Oct 2007
513 IQ
#16
do you have many leatherbound books? hahaha

looking good my man, moar pics =
------

Shwiggity.
lumberjack
The Axe Man
Join date: Feb 2006
2,905 IQ
#18
Quote by deftonesordie
do you have many leatherbound books? hahaha

looking good my man, moar pics =



WINNER

Anyways, this is going to be a lot of fun to watch!
Quote by ormsby guitars
Lumberjack
deftonesordie
ENGL Fireball 100 Abuser
Join date: Oct 2007
513 IQ
#20
what do you plan on planing it to? (just curious)
------

Shwiggity.
guitarcam123
Registered User
Join date: Mar 2008
1,708 IQ
#21
how much did you end up getting the wood for?

Also i vote traditional tele bridge but in black with chrome saddles
Nice looking mahogany too!
divinorum69
Construction Manager
Join date: May 2007
1,803 IQ
#22
expensive, 50. But its because its imported. Ill save with the neck since ill use a national wood.

Im gonna take it to a woodshop tomorrow, gonna pay for the planing

(by planing im referring to the thing you do to take wideness of the body. For example im going to take almost 5 mm, so from 52mm I go to 47mm.)
chuckflan333
Mmm, yeah
Join date: Sep 2005
778 IQ
#23
The planer would affect thickness.
Gear
Fender Thinline Telecaster Deluxe

1983 Aria Pro II XX Deluxe Flying V

2007 S101 EGU34

1963 Kay Vanguard

1964 Kay Vanguard

AXL Badwater SRO

Hondo Strat

1974 Acoustic(brand) 134 4x10 combo

Epiphone Valve Jr.
guitarcam123
Registered User
Join date: Mar 2008
1,708 IQ
#25
no worries,
thats a pretty good price, its no lumber yard price but its good for internet price (it is from the net right?)
guitarcam123
Registered User
Join date: Mar 2008
1,708 IQ
#27
say fack next time. for some reason it amuses me and makes me laugh


....
bv310
GB&C's Very Own Brock!!!
Join date: Oct 2007
1,721 IQ
#31
5kg! Wow. that's nice
R.I.P. Les Paul, 1915-2009

A man chooses, a slave obeys.
guitarcam123
Registered User
Join date: Mar 2008
1,708 IQ
#32
thats looks very nice, it think you should do a clear coat or stain
divinorum69
Construction Manager
Join date: May 2007
1,803 IQ
#35
Quote by LeviMan_2001
no belt sander or anything? wow impressive. I vote tele style bridge, i like classic style stuff. Whats the story with the neck wood? i've never heard of it.


No belt sander, all done by hand.

Still havnt got the wood. Will be Guatambu, Argentine wood. Similiar to maple, Semi-Hard wood.



Thats a crappy national guitar with that wood, though it does not mean the wood is bad. It is very much used here for lots of things. It a lot cheaper than maple since maple is northern hemisphere wood, and we are in the southern Hemisphere.
guitarcam123
Registered User
Join date: Mar 2008
1,708 IQ
#36
How cheap do you get it?
I can't seem to find cheap wood anywhere, except pine
divinorum69
Construction Manager
Join date: May 2007
1,803 IQ
#38
Okay got tehs ebony for the neck.





and some hardware I finally went with bridge plate, sorry to disapoint some people it just looked it was gonna be easier to finish
ebony cost me around 12 dollars, its B quality, but I compared it to an AA, or at least what they claim in the shop and it was the same, very little difference in cosmetics and feel but price was higher, 28 dollars. So went with B and im proud of it. Also bought a radius sanding block which cost me a alot (20 dollars) because there impossible to get here, as I said before no EBAY, no StewMac, no warmoth and all those places which simplify a luthiers life in work and money wise

well thats all for today...

Cheers



EDIT: maybe ya cant tell but I sanded and I filed handwise all the left side of the guitar and the horn. Took me about 6-8 hours of hot work, its hot here, we are in summer 25-35 °C depending on clouds and wind
Last edited by divinorum69 at Dec 9, 2008,
deftonesordie
ENGL Fireball 100 Abuser
Join date: Oct 2007
513 IQ
#39
wanna trade? we're -15°C right now, I'd kill for a warm day again

Looking good, do you have any rasps or a spokeshave? it might make the finishing process a lot easier for the edges
------

Shwiggity.
divinorum69
Construction Manager
Join date: May 2007
1,803 IQ
#40
Quote by deftonesordie
wanna trade? we're -15°C right now, I'd kill for a warm day again

Looking good, do you have any rasps or a spokeshave? it might make the finishing process a lot easier for the edges


None of them. Ill never trade for cold, i prefer sweating hot than freezing cold!
