Been working on a delay pedal for quite some time now, just got it etched up and ready to go and it sounds great, clips later, maybe.





Sorry for big pics.
Gearz:
Squier classic vibe 50's strat, modded.
Dunlop 535q
Korg Pitchblack
Carvin X100B

Coming soon to a pedal board near you:
Analogman Sunface
Lovepedal E6
Area 51 wah
Skreddy Lunar Module
Malekko 616 Ekko
#4
That's just fantastic.
Quote by Altered_Carbon
That's some bony hipster sex, which may be the best kind.
#5
What circuit is it based on? Analog I'm assuming since I don't see a giant chip in there?
1988 Epi LP Custom
Peavey Wolfgang Special
G&L ASAT Classic Tribute
PRS SE Soapbar
PRS SE Custom
Jet City JCA20H
VOX lil' Night Train
Celestion Greenback and Vintage 30 Speakers
Assorted Pedals and swag
#7
Quote by guitarcam123
wow nice
I like how you recessed the knobs and the name haha

I don't think the knobs are recessed in there..

I thought that, too, at first, but I think it's just a decal on there (almost positive about that)


...but yeah, what schematic is that from?
#9
Quote by The_rylan
What circuit is it based on? Analog I'm assuming since I don't see a giant chip in there?

It is digital actually. That big IC is a PT2399 digital delay chips, no analog BDD chips in this one.

The smaller IC is an op-amp...for buffering in this effect if I remember correctly.
#10
Quote by The_rylan
What circuit is it based on? Analog I'm assuming since I don't see a giant chip in there?

no....its the rebote delay from tonepad, digital based on a PT2339

and i dont think the knobs are recessed, there are just circles etched under them to give it that effect

and its not a decal, its etched in acid
#11
