i need a good electric, so i build one!


Body: 1 peice Ash
Neck: GFS Maple, tele style
Bridge: TOM string Thru
Bridge Pup: Crunchy Pat Chrome cover
Neck Pup: Lipstick style, 6k
Controls: 1 vol, 1 tone, 3 way toggle
Black Sparkle Pickgaurd
Red Sunburst Finish
Grover 18:1 Mini Rotomatic, black.


Pics:
Body Wood

Back

Mock Up

Neck

Nut Close Up

Inlay (the worst one)

PickGaurd
Just call me Julius, J, etc.
Taking an Internet break for a while, will come on when I can.
#2
Neck Blank

Doesnt fit in pickgaurd, had to make it bigger

Rough Cut

Neck Pocket (should i route this first, or cut it to the line then do it?)

Headstock Shaped

Ill make a headstock veneer/control plate out of this peice

needs some TLC. Any hints on how to get it back to the final line?
Just call me Julius, J, etc.
Taking an Internet break for a while, will come on when I can.
#3
A Tele with a humbucker in the bridge... yummy.

The neck is looking pretty good from the pictures you showed.

EDIT: Sorry, I can't answer your question.
Quote by user_nameless
You can go ahead and sponge my bob.

/notfunnyatalljoke.


Quote by halo43
When you date a vegetarian, you're the only meat they'll ever eat.
#4
Quote by TMF128
A Tele with a humbucker in the bridge... yummy.

The neck is looking pretty good from the pictures you showed.

Its from GFS, pretty good for 30$!
Order came in less then a week to eastern Canada, i was impressed yet again.
Just call me Julius, J, etc.
Taking an Internet break for a while, will come on when I can.
#5
nice man! good luck with your project
i'm looking forward to seeing the final product
#6
Quote by I6or
nice man! good luck with your project
i'm looking forward to seeing the final product

ill upload the kisakae later tonight!
Just call me Julius, J, etc.
Taking an Internet break for a while, will come on when I can.
Last edited by nowa90 at Jul 1, 2010,
#7
I can has more visiters?
Just call me Julius, J, etc.
Taking an Internet break for a while, will come on when I can.
#8
Quote by nowa90
needs some TLC. Any hints on how to get it back to the final line?



Not sure what that bit is, can you upload a photo that's not so close?
#9
You could use a rasp, router,oscillating sander, or a sander attachment in a drill.
Just call me Bobby
Member of the official GB&C "Who to Listen to" list
Quote by mikeyElite
you build guitars worthy of sexual favors

Quote by Invader Jim
if this party gets any livelier a funeral is gonna break out.
#10
Quote by lostcreation333
Not sure what that bit is, can you upload a photo that's not so close?

its the lower horn.

I just put a straight bit in the router and went around 4 times, about to go on my last, then ill sand it down to thefinal (~0.1mm left). Much easier then i thought. Ill do neck pocket tomorow and maybe control cavity/pickups.
Just call me Julius, J, etc.
Taking an Internet break for a while, will come on when I can.
#11
I'de use a spindle sander if you have one.




Quote by dogismycopilot
Absent Mind, words cant express how much i love you. Id bone you, oh yea.

Quote by lumberjack
Absent Mind is, as usual, completely correct.

Quote by littlemurph7976
Id like to make my love for Neil public knowledge as he is a beautiful man
#13
Quote by -MintSauce-
This... or a rasp, followed by sanding. A drum/spindle sander would be easiest by far.

i decided to do it (no other option :P) to just run the router along the outside edge. I had on problem (went deep) on the inside horn and belly carve, but i was sub-consciously thinking about it before, so its all good.
Just call me Julius, J, etc.
Taking an Internet break for a while, will come on when I can.
#15
alright, i just routed out for the pickups, and cleaned up the neck pocket/whole body side.
Neck fits in, but not enough to hold the body with, but im pleased as a i free handed it/first neck pocket. I tried to clamp a peice as a guide, and it actually slipped and took out .7mm out of the side :S. Is it possible to put epoxy or somethingin a neck pocket for a bolt on neck?

Back to the grind before sunlight goes. Ill post pics once the sun sets (1-2 hours?)
Just call me Julius, J, etc.
Taking an Internet break for a while, will come on when I can.
#16
Quote by nowa90
alright, i just routed out for the pickups, and cleaned up the neck pocket/whole body side.
Neck fits in, but not enough to hold the body with, but im pleased as a i free handed it/first neck pocket. I tried to clamp a peice as a guide, and it actually slipped and took out .7mm out of the side :S. Is it possible to put epoxy or somethingin a neck pocket for a bolt on neck?

Back to the grind before sunlight goes. Ill post pics once the sun sets (1-2 hours?)



Use a 2-part filler - the stuff you buy at an auto repair store.
#17
Looks sexy man.
My Tele Project!

Cheapy Johnson Steel String Acoustic
Les Paul Ripoff w/ SD SH2 and SH4
Modded Crate V18 2x12 w/ Weber Speakers
Squier Deluxe 5-string Active J-Bass
Acoustic B100 15" Bass Combo Amp
Gray VS Jekyll & Hyde
Vox V847A Wah
#18
thank you, tomorrow before the zappa plays zappa concert i have to:
scrape the sides
drill holes for tom
drill hole between pup routes for cable
route out control panel
figure out where the neck bolts will go
countersink the neck ferrules.

and see where i go from there :P
Just call me Julius, J, etc.
Taking an Internet break for a while, will come on when I can.
#20
Quote by forsaknazrael
how's the fretjob on the GFS? Need any leveling or anything? Any of them stick out?

its pretty nice, better then squiers. They arent gleaming or anything, im going to polish them up when i get the chance. Defiantly worth the 30$
Just call me Julius, J, etc.
Taking an Internet break for a while, will come on when I can.
#22
Quote by forsaknazrael
Cool, I might pick one up for my own Tele build then.
it was fairly easy to shape the headstock too, which is always nice.
Anyone know if i have to put a finish on maple fretboards? I may just to get that tele look, but may not due to laziness :P

Routing is going good, made some adjustments (lower horn is deeper, all 21 frets are clear )
im getting a scraper and workbench tonight while im at ZPZ, so tomorrow i can clean up those routes and maybe drill the holes for ferrules/neck pocket.
Just call me Julius, J, etc.
Taking an Internet break for a while, will come on when I can.
#23
you HAVE to have some kind of finish on a maple fretboard. A clear coat is preferred, but you can due a couple coats of oil if you wish. Though you will have to reapply more oil ever year or so.
Just call me Bobby
Member of the official GB&C "Who to Listen to" list
Quote by mikeyElite
you build guitars worthy of sexual favors

Quote by Invader Jim
if this party gets any livelier a funeral is gonna break out.
#24
what happens if i dont clear coat it? Looks like i am. Is there an easy way to cover the fret wires, or does it matter?
Just call me Julius, J, etc.
Taking an Internet break for a while, will come on when I can.
#25
If you don't put a finish on it maple gets grimy as ****, and not in the good way like on a vintage guitar. Don't worry above covering the frets. Just steel wool them after the finish is set and they'll be fine.
My Tele Project!

Cheapy Johnson Steel String Acoustic
Les Paul Ripoff w/ SD SH2 and SH4
Modded Crate V18 2x12 w/ Weber Speakers
Squier Deluxe 5-string Active J-Bass
Acoustic B100 15" Bass Combo Amp
Gray VS Jekyll & Hyde
Vox V847A Wah
#26
good to know, now uploading pics. Ill post them before the concert
Just call me Julius, J, etc.
Taking an Internet break for a while, will come on when I can.
#30
i actually HAVE done some work to it (planing, sanding, and drilling):P Ill take some pics once i get out of the city and home. Ill have some questions to ask

thanks for the support
Just call me Julius, J, etc.
Taking an Internet break for a while, will come on when I can.
#31
that neck pocket looks beaut! i think this is going to turn out great. good job so far, looking forward to seeing how this turns out.
'The Blues is Easy to Play, but Hard to Feel'
Jimi Hendrix
#32
ive done some sanding and rounded the edge for the arm. Once i go to a freinds parents house to help me with it, it should be ready for painting.
Just call me Julius, J, etc.
Taking an Internet break for a while, will come on when I can.
#33
This looks amazing!

If I had the time/money/equipment I'd wanna try this
#35
This is looking pretty nice. Like the shaped heel and everythnig. Dunno if i'm so keen on the grain of that headstock veneer though.
EH


"Show me war; show me pestilence; show me the blood-red hands of retribution..."
#37
i worked for 6 hours on it today, and should finish this week.
Today we got the neck on, shaped the heel to an AANJ, ferrules all set up, amke a contral cavity cover, inlayed the headstock, predrilled all screw holes, drawknife'd the arm contour and a little back contour too, and cut out the pup place for the neck in the pickgaurd.
It sounds so cliche, but the camera's batteries are dead and we cant find the charger Ill see if I can borrow one. Tomorrow after jazz I'll re-route eveything with a guide, and then start to wire it up. Stoked!


Quote by Kiery
This looks amazing!

If I had the time/money/equipment I'd wanna try this

Go for it! Its buttloads of fun, and this one only cost me about 180CAD!

Quote by salgala2000
WOw i can't believe i've never seen this thread before.

It looks nice keep the pics coming!!

thank you man!

Quote by hardcore81
how'd you figure out where to put the ferrules?

i just roughed it and went with what i thought looked ok anglewise. Just make sure you have it straight with the bridge or it'd look funky

Quote by eddiehimself
This is looking pretty nice. Like the shaped heel and everythnig. Dunno if i'm so keen on the grain of that headstock veneer though.

thank you. Good thing i didnt end up putting it on anyways :P
Just call me Julius, J, etc.
Taking an Internet break for a while, will come on when I can.
Last edited by nowa90 at Sep 26, 2010,
#38
HOLY SHIT HOLY SHIT MEGA UPDATE
Back

Front
Headstock inlay! (secretly a J!)

Mock-up


The first layer of varnish in one now, another hour of drying to go. How many layers do you think I should put on; 3?
Just call me Julius, J, etc.
Taking an Internet break for a while, will come on when I can.
Last edited by nowa90 at Oct 30, 2010,
#39
aww and i just found this thread and its already almost over... its like finding a movie you really want to watch right at the end and it isn't one again for months.... LAME. awesome build though, love the way the color scheme. Any significance of the headstock logo? looks vaguely familiar to me for some reason so hows it play and sound and such? excellent job on the control panel cover as well, I always hated how the rest of my tele looked pristine but my metal control panel cover always had finger smudges and the such, its like a pretty girl with two much eye liner . Anyways awesome job ill be stopping back to see the finished finished .


I wish my milkshake brought all the girls to the yard

Guitars:
Heritage Prospect Classic (my baby)
Steinberger GM4 (my take no prisoners up yours guitar)

Amp:
Hughes and Kettner Duotone Combo

Other misc. crap
#40
Quote by ThePushMan
aww and i just found this thread and its already almost over... its like finding a movie you really want to watch right at the end and it isn't one again for months.... LAME. awesome build though, love the way the color scheme. Any significance of the headstock logo? looks vaguely familiar to me for some reason so hows it play and sound and such? excellent job on the control panel cover as well, I always hated how the rest of my tele looked pristine but my metal control panel cover always had finger smudges and the such, its like a pretty girl with two much eye liner . Anyways awesome job ill be stopping back to see the finished finished .



Thanks man! No real importance, i just sketched it on from my head, and the first sketch fit perfectly. Its secretly a J i
I wont be able to tell you untill its finished, but the neck is nice and smooth and nicely shaped.


Today i did 3 more layers of varnish. Body is done and needs 24 hours to completly harden, but the maplei s so thirsty and needs another 2-3
While the neck dries tomorrow, ill start the wireing/mounting hardware
Just call me Julius, J, etc.
Taking an Internet break for a while, will come on when I can.
